FSP PC Power Supply ATX 12V ver.2.3 series APN,(85) FSP300-60APN manufacturer from China AS Power Co., ltd

Place of Origin:

Sichuan, China (Mainland)

Product Detail

model number: FSP300-60APN
Dimension :140 x 150 x 86 mm
Application : For PC
Watt : 300,400,500
PFC : Active
Features
Efficiency meet 80plus Bro

model number: FSP300-60APN

Dimension :140 x 150 x 86 mm

Application : For PC

Watt : 300,400,500

PFC : Active

Features

Efficiency meet 80plus Bronze level requirement

Low ripple & noise

Resettable power shut down

nternal 12 cm fan

100% burn-in test

MTBF: 100K hours at 25°C

Protection Specifications

Over-voltage protection:+3.3V, +5V, +12V1, +12V2

Over-current protection:+3.3V, +5V, +12V1, +12V2

General Specifications:

Efficiency:82%, 85%, 82%

Environmental Specifications

Operating conditions: ambient temperature 0°C~25°C

Storage and shipping conditions:ambient temperature -20°C ~ +65°C

Dielectric withstand:input / output 1800 VAC for 1 second,input to frame ground 1800VAC for 1 second

Output

watts:300w

outputs:+3.3V 21A,+15V 15A,+12V1 15A,+12V2 15A,-12V 0.3A,+5Vsb 2.5A
